NI PXIe-5164 PXI​示波器 可编程电源信号动态分析仪

NI PXIe-5164 PXI示波器是一款功能强大的测试仪器，它结合了示波器的时域和频域分析能力与PXI系统的灵活性。以下是关于NI PXIe-5164 PXI示波器的主要特性和功能的清晰归纳：

1. 技术规格：
• 通道数：多达8个通道，用于同时采集和分析多个信号。
• 采样速率：高达12.5GS/s，提供极快的信号捕获能力。
• 模拟带宽：5GHz，确保能够准确捕获高频信号。
2. 主要功能：
• 时域和频域分析：NI PXIe-5164 PXI示波器能够采集并分析时域和频域模拟信号，为工程师提供全面的信号分析手段。
• PXI平台优势：作为PXI系统的一部分，该示波器具有高度的灵活性和可扩展性，能够与其他PXI模块协同工作，满足复杂的测试需求。
• 可编程FPGA：内置用户可编程的FPGA，允许用户根据特定需求定制测试方案，提高测试效率。
3. 应用领域：
• 该示波器广泛应用于电子、交通、航天、汽车、电气等领域，用于信号分析、故障诊断、系统验证等任务。
4. 价格与供应商：
• 价格可能因供应商和地区而异。例如，在厦门雄霸电子商务有限公司，NI PXIe-5164 PXI示波器的起售价为8.89万元。
5. 其他特点：
• 触发模式：PXI示波器支持多种触发模式，方便用户根据信号特点选择合适的触发方式。
• 深度板载内存：提供大量存储空间，用于捕获和分析长时间信号。
• 仪器驱动程序：包括数据流和分析功能，方便用户进行高级信号处理和分析。
6. 编程与定制：
• 由于其可编程FPGA和开放的软件接口，NI PXIe-5164 PXI示波器可以根据特定需求进行编程和定制，为用户提供定制化的测试解决方案。

The NI PXIe-5164 PXI oscilloscope is a powerful test instrument that combines the time and frequency domain analysis capabilities of an oscilloscope with the flexibility of a PXI system. The following is a clear summary of the main features and functions of the NI PXIe-5164 PXI oscilloscope:

Technical specifications:

Number of channels: Up to 8 channels for simultaneous acquisition and analysis of multiple signals.

Sampling rate: Up to 12.5GS/s, providing extremely fast signal capture capability.

Analog bandwidth: 5GHz, ensuring accurate capture of high-frequency signals.

Main functions:

Time domain and frequency domain analysis: The NI PXIe-5164 PXI oscilloscope can collect and analyze analog signals in time domain and frequency domain, providing engineers with a comprehensive signal analysis means.

PXI Platform advantages: As part of the PXI system, the oscilloscope has a high degree of flexibility and scalability, and can work with other PXI modules to meet complex test needs.

Programmable FPGA: Built-in user programmable FPGA, allowing users to customize the test scheme according to specific needs, improve test efficiency.

Application field:

The oscilloscope is widely used in electronics, transportation, aerospace, automotive, electrical and other fields, for signal analysis, fault diagnosis, system verification and other tasks.

Price and Supplier:

Prices may vary by supplier and region. At Xiamen Xiongba E-commerce Co., for example, the NI PXIe-5164 PXI oscilloscope starts at 88,900 yuan.

Other features:

Trigger mode: PXI oscilloscope supports a variety of trigger modes, which is convenient for users to choose the appropriate trigger mode according to the characteristics of the signal.

Deep onboard memory: provides a large amount of storage space for capturing and analyzing long-term signals.

Instrument driver: Includes data flow and analysis functions to facilitate advanced signal processing and analysis.

Programming and Customization:

Thanks to its programmable FPGA and open software interface, the NI PXIe-5164 PXI oscilloscope can be programmed and customized according to specific needs, providing users with customized test solutions.
